Tunnel Boring Machines

Full-face tunnel boring machines for metro, road, rail, water and utility tunnels: slurry, EPB, hard-rock, multi-mode and shaft configurations from 0.55 m micro-bore to 23 m mega-bore.

Key Specifications

0.55 - 23 m

Diameter Range

Up to 42,784 kNm

Cutterhead Torque

Up to 4,100 t

Machine Weight

Up to 9,755 kW

Installed Power

Up to 8 bar

Working Pressure

5 families

TBM Configurations

AU-based

Commercial & Aftermarket

Worldwide

OEM Deployment

Featured Models

EPB TBM

Earth pressure balance shields for clay, sandy soil and mixed soft-to-hard ground. Open, semi-open and closed excavation modes for adaptable, cost-efficient metro and utility tunnelling, and the most widely deployed configuration in CRCHI's TBM range.

Multi-mode TBM

Single-shield machines configured to switch between EPB and slurry pressure-balance excavation modes on the same drive. Built for mixed-face urban alignments where ground transitions between clay, water-bearing sand and weathered rock without retrieving or rebuilding the machine, suited to mixed-ground metro packages crossing multiple ground regimes.

Double-Shield TBM

Hard-rock TBM with telescopic forward and gripper shields for fast continuous boring and segmental lining installation in poor or fractured rock. Shielded operation through fault zones and broken ground suits long water-conveyance, hydropower headrace and underground rail drives where ground quality varies along the alignment.
